The HMI series is a highly reliable and cost-effective multi parameter water quality controller for data collection, communication, logging, alarming, control and analysis applications.

The unit supports built-in I/Os, cellular/ ethernet, bluetooth, RS485 and GPS modules. The RS485 port is able to connect maximum up to 8 SMR smart digital sensors includes free chlorine, PH, ORP, temperature, conductivity, resistivity, dissolved oxygen, turbidity, salinity, suspended solid, ammonium, flow, velocity, level, pressure etc.

Features:

• Robust IP66/NEMA4X enclosure - outdoor solution without the need for a cabinet

• Plug & measure - Seamless connection up to 8 SMR smart digital sensors

• 7" High resolution touch screen, LCD display

• Built-in data logger - Up to 2,000,000 log storage

• PID control analogue outputs

• Support cellular and ethernet hot backup redundant communication

• Built-in battery Backup, up to 30 Days Measurement, Alarm and Logging during Power Outages

• Alarm Log, SMS Meassaging and Control Outputs

• System Self Diagnosis and Sensors Monitoring

• Built-in Standard Modbus TCP Communication Protocol

• Integral FTP Protocol, Directly Upload Log Files to User Server

• Standard OPC Server Software to Seamlessly Connect SCADA Software and Database

• Cloud Based Platform for Configuration, Operation, Monitoring, Alarm, Control and Data Analysis
